CC1110-RTY1 Datasheet(PDF) 134 Page - Texas Instruments |
|
|
|||||||||||||||||||||||||||||
CC1110-RTY1 Datasheet(HTML) 134 Page - Texas Instruments |
|
|
134 / 203 page  CC1110 CC1110 PRELIMINARY Datasheet (Rev. 1.01) SWRS033A Page 134 of 202 13.11 Power On Reset The CC1110 includes a Power On Reset (POR) in order to protect the memory contents during supply voltage variations and provide correct initialization during power-on. When power is initially applied to the CC1110 the Power On Reset (POR) will hold the device in reset state until the supply voltage reaches above the Power On Reset voltage as defined in Table 4 on page 12. Figure 26 shows the POR operation with the 1.8V (typical) regulated supply voltage together with the active low reset signal shown in the bottom of the figure. The cause of the last reset can read from the register bits SLEEP.RST. 0 UNREGULATED 1.8V REGULATED POR RESET ASSERT FALLING VDD POR RESET DEASSERT RISING VDD VOLT POR RESET X X Figure 26 : Power On Reset Operation |
|
