CC1110

CC1110 PRELIMINARY Datasheet (Rev. 1.01) SWRS033A

Page 200 of 202

20.1 Package thermal properties

Thermal resistance

Air velocity [m/s]

Rth,j-a [K/W]

25.6

Table 54: Thermal properties of QLP 36 package

20.2 Soldering information

The recommendations for lead-free reflow in IPC/JEDEC J-STD-020C should be followed.

20.3 Tray specification

Tray Specification

Package

Tray Length

Tray Width

Tray Height

Units per Tray

QLP 36

322.6 mm

135.9 mm

7.62 mm

490

Table 55: Tray specification

20.4 Carrier tape and reel specification

Carrier tape and reel is in accordance with EIA Specification 481.

Tape and Reel Specification

Package

Carrier Tape

Width

Component

Pitch

Hole Pitch

Reel

Diameter

Reel Hub

Diameter

Units per Reel

QLP 36

16 mm

12 mm

4 mm

inches

7 inches

2500

Table 56: Carrier tape and reel specification

21 Ordering Information

Ordering part number

Description

Minimum Order Quantity (MOQ)

1267

CC1110-RTY1

CC1110, QLP36 package, RoHS compliant Pb-free

assembly, trays with 490 pcs per tray. System-on-

Chip RF Transceiver

490

1268

CC1110-RTR1

CC1110, QLP36 package, RoHS compliant Pb-free

assembly, tape and reel with 2500 pcs per reel.

System-on-Chip RF Transceiver

2500

1269

CC1110DK

CC1110 Development Kit

Table 57: Ordering Information
