Section 16 USB Function Module (USB)
Rev.1.00 Jun. 07, 2006 Page 786 of 1102
REJ09B0294-0100
16.4
Interrupt Sources
This module has five interrupt signals. Table 16.6 shows the interrupt sources and their
corresponding interrupt request signals. The USBINTN interrupt signals are activated at low level.
The USBINTN interrupt requests can only be detected at low level (specified as level sensitive).
Table 16.6
Interrupt Sources
Register
Bit
Transfer
Mode
Interrupt
Source
Description
Interrupt
Request
Signal
DTC
Activation
DMAC
Activation
IFR0
0
EP0i_TS*
EP0i transfer
complete
USBINTN2 or
USBINTN3
×
×
1
Control
transfer
(EP0)
EP0i_TR*
EP0i transfer
request
USBINTN2 or
USBINTN3
×
×
2
EP0o_TS*
EP0o receive
complete
USBINTN2 or
USBINTN3
×
×
3
SETUP_TS*
Setup command
receive complete
USBINTN2 or
USBINTN3
×
×
4
Bulk_in
transfer
(EP2)
EP2_EMPTY
EP2 FIFO empty
USBINTN2 or
USBINTN3
×
USBINTN1
5
EP2_TR
EP2 transfer
request
USBINTN2 or
USBINTN3
×
×
6
Bulk_out
transfer
(EP1)
EP1_FULL
EP1 FIFO Full
USBINTN2 or
USBINTN3
×
USBINTN0
7
Status
BRST
Bus reset
USBINTN2 or
USBINTN3
×
×
IFR1
0
Status
VBUSF
USB
disconnection
detection
USBINTN2 or
USBINTN3
×
×
1
EP3_TS
EP3 transfer
complete
USBINTN2 or
USBINTN3
×
×
2
Interrupt_in
transfer
(EP3)
EP3_TR
EP3 transfer
request
USBINTN2 or
USBINTN3
×
×
3
Status
VBUSMN
VBUS connection
status
—
×
×
4
5
—
Reserved
—
—
—
—
6
7
