H8SX/1663 Datasheet(PDF) 1063 Page - Renesas Technology Corp |
|
|
|||||||||||||||||||||||||||||
H8SX/1663 Datasheet(HTML) 1063 Page - Renesas Technology Corp |
|
|
1063 / 1158 page  Section 24 List of Registers Rev.1.00 Jun. 07, 2006 Page 1011 of 1102 REJ09B0294-0100 Register Abbreviation Bit 31/23/15/7 Bit 30/22/14/6 Bit 29/21/13/5 Bit 28/20/12/4 Bit 27/19/11/3 Bit 26/18/10/2 Bit 25/17/9/1 Bit 24/16/8/0 Module PFICR PF7ICR PF6ICR PF5ICR PF4ICR PF3ICR PF2ICR PF1ICR PF0ICR I/O port PORTH PH7 PH6 PH5 PH4 PH3 PH2 PH1 PH0 PORTI PI7 PI6 PI5 PI4 PI3 PI2 PI1 PI0 PHDR PH7DR PH6DR PH5DR PH4DR PH3DR PH2DR PH1DR PH0DR PIDR PI7DR PI6DR PI5DR PI4DR PI3DR PI2DR PI1DR PI0DR PHDDR PH7DDR PH6DDR PH5DDR PH4DDR PH3DDR PH2DDR PH1DDR PH0DDR PIDDR PI7DDR PI6DDR PI5DDR PI4DDR PI3DDR PI2DDR PI1DDR PI0DDR PHICR PH7ICR PH6ICR PH5ICR PH4ICR PH3ICR PH2ICR PH1ICR PH0ICR PIICR PI7ICR PI6ICR PI5ICR PI4ICR PI3ICR PI2ICR PI1ICR PI0ICR PDPCR PD7PCR PD6PCR PD5PCR PD4PCR PD3PCR PD2PCR PD1PCR PD0PCR PEPCR PE7PCR PE6PCR PE5PCR PE4PCR PE3PCR PE2PCR PE1PCR PE0PCR PFPCR PF7PCR PF6PCR PF5PCR PF4PCR PF3PCR PF2PCR PF1PCR PF0PCR PHPCR PH7PCR PH6PCR PH5PCR PH4PCR PH3PCR PH2PCR PH1PCR PH0PCR PIPCR PI7PCR PI6PCR PI5PCR PI4PCR PI3PCR PI2PCR PI1PCR PI0PCR P2ODR P27ODR P26ODR P25ODR P24ODR P23ODR P22ODR P21ODR P20ODR PFODR PF7ODR PF6ODR PF5ODR PF4ODR PF3ODR PF2ODR PF1ODR PF0ODR PFCR0 CS7E CS6E CS5E CS4E CS3E CS2E CS1E CS0E PFCR1 CS7SA CS7SB CS6SA CS6SB CS5SA CS5SB CS4SA CS4SB PFCR2 — CS2S BSS BSE RDWRS RDWRE ASOE — PFCR4 A23E A22E A21E A20E A19E A18E A17E A16E PFCR6 — LHWROE — — TCLKS — — — PFCR7 DMAS3A DMAS3B DMAS2A DMAS2B DMAS1A DMAS1B DMAS0A DMAS0B PFCR9 TPUMS5 TPUMS4 TPUMS3A TPUMS3B TPUMS2A TPUMS2B TPUMS1A TPUMS1B PFCRB — — — — ITS11 ITS10 ITS9 ITS8 PFCRC ITS7 ITS6 ITS5 ITS4 ITS3 ITS2 ITS1 ITS0 SSIER SSI15 — — — SSI11 SSI10 SSI9 SSI8 INTC SSI7 SSI6 SSI5 SSI4 SSI3 SSI2 SSI1 SSI0 DSAR_0 DMAC_0 DDAR_0 |
|
