1121 / 1158 page  Section 25 Electrical Characteristics Rev.1.00 Jun. 07, 2006 Page 1069 of 1102 REJ09B0294-0100 TRp B φ RAS LUCAS, LLCAS OE TRr tCSD2 tCSR1 tCASD1 tCASD1 tCSD1 TRc1 TRc2 Figure 25.25 CAS Before RAS Refresh Timing TRp TRrw tCSD2 tCSR2 tCASD1 tCSD1 tCASD1 TRr TRc1 TRcw TRc2 B φ RAS LUCAS, LLCAS OE Figure 25.26 CAS Before RAS Refresh Timing (Wait Cycle Inserted) B φ RAS LUCAS, LLCAS OE TRp TRr tCSD2 tCASD1 tCSD2 tCASD1 tRPS2 TRc3 TRc4 Tp Self refresh DRAM access Tr Figure 25.27 Self-Refresh Timing (After Leaving Software Standby: RAST = 0) |
|
