Section 19 Serial Communication Interface (SCI, IrDA, CRC)
Rev. 2.00 Sep. 24, 2008 Page 898 of 1468
REJ09B0412-0200
Operating Frequency P
φ (MHz)
25
30
33
35
Bit Rate
(bit/s)
n
N
Error
(%)
n
N
Error
(%)
n
N
Error
(%)
n
N
Error
(%)
110
3
110
–0.02
3
132
0.13
3
145
0.33
3
154
0.23
150
3
80
0.47
3
97
–0.35
3
106
0.39
3
113
–0.06
300
2
162
–0.15
2
194
0.16
2
214
–0.07
2
227
–0.06
600
2
80
0.47
2
97
–0.35
2
106
0.39
2
113
–0.06
1200
1
162
–0.15
1
194
0.16
1
214
–0.07
1
227
–0.06
2400
1
80
0.47
1
97
–0.35
1
106
0.39
1
113
–0.06
4800
0
162
–0.15
0
194
0.16
0
214
–0.07
0
227
–0.06
9600
0
80
0.47
0
97
–0.35
0
106
0.39
0
113
–0.06
19200
0
40
–0.76
0
48
–0.35
0
53
–0.54
0
56
–0.06
31250
0
24
0.00
0
29
0
0
32
0
0
34
0.00
38400
0
19
1.73
0
23
1.73
0
26
–0.54
0
27
1.73
Note:
In SCI_2, 5, and 6, this is an example when the ABCS bit in SEMR_2, 5, and 6 is 0.
When the ABCS bit is set to 1, the bit rate is two times.
Table 19.5
Maximum Bit Rate for Each Operating Frequency (Asynchronous Mode)
P
φ (MHz)
Maximum
Bit Rate
(bit/s)
n
N
P
φ (MHz)
Maximum
Bit Rate
(bit/s)
n
N
8
250000
0
0
17.2032
537600
0
0
9.8304
307200
0
0
18
562500
0
0
10
312500
0
0
19.6608
614400
0
0
12
375000
0
0
20
625000
0
0
12.288
384000
0
0
25
781250
0
0
14
437500
0
0
30
937500
0
0
14.7456
460800
0
0
33
1031250
0
0
16
500000
0
0
35
1093750
0
0
