background image
Section 21 I
2C Bus Interface 2 (IIC2)
Rev. 2.00 Sep. 24, 2008 Page 1040 of 1468
REJ09B0412-0200
Bit
Bit Name
Initial
Value
R/W
Description
3
SCLO
1
R
This bit monitors the SCL output level.
When reading and SCLO is 1, the SCL pin outputs a
high level. When reading and SCLO is 0, the SCL pin
outputs a low level.
2
1
Reserved
This bit is always read as 1.
1
IICRST
0
R/W
IIC Control Module Reset
This bit reset the IIC control module except the I
2C
registers. If hang-up occurs because of communication
failure during I
2C operation, by setting this bit to 1, the
I
2C control module can be reset without initializing the
registers.
0
1
Reserved
This bit is always read as 1.
