Section 25 Flash Memory

Rev. 2.00 Sep. 24, 2008 Page 1198 of 1468

REJ09B0412-0200

(f)

Memory Read

The boot program will return the data in the specified address.

Command

H'52

Size

Area

Read address

Read size

SUM

• Command: H'52 (1 byte): Memory read

• Size (1 byte): Amount of data that represents the area, read address, and read size (fixed at 9)

• Area (1 byte)

H'00: User boot MAT

H'01: User MAT

An address error occurs when the area setting is incorrect.

• Read address (4 bytes): Start address to be read from

• Read size (4 bytes): Size of data to be read

• SUM (1 byte): Checksum

Response

H'52

Read size

Data

···

SUM

• Response: H'52 (1 byte): Response to memory read

• Read size (4 bytes): Size of data to be read

• Data (n bytes): Data for the read size from the read address

• SUM (1 byte): Checksum

Error Response

H'D2

ERROR

• Error response: H'D2 (1 byte): Error response to memory read

• ERROR: (1 byte): Error code

H'11: Sum check error

H'2A: Address error

The read address is not in the MAT.

H'2B: Size error

The read size exceeds the MAT.
