Section 29 List of Registers
Rev. 2.00 Sep. 24, 2008 Page 1345 of 1468
REJ09B0412-0200
Register
Abbreviation
Reset
Module
Stop State Sleep
All-Module-
Clock-Stop
Software
Standby
Deep Software
Standby
Hardware
Standby
Module
P1DDR
Initialized
Initialized*
1
Initialized
P2DDR
Initialized
Initialized*
1
Initialized
P3DDR
Initialized
Initialized*
1
Initialized
P6DDR
Initialized
Initialized*
1
Initialized
PADDR
Initialized
Initialized*
1
Initialized
PBDDR
Initialized
Initialized*
1
Initialized
PCDDR
Initialized
Initialized*
1
Initialized
PDDDR
Initialized
Initialized*
1
Initialized
PEDDR
Initialized
Initialized*
1
Initialized
PFDDR
Initialized
Initialized*
1
Initialized
P1ICR
Initialized
Initialized*
1
Initialized
P2ICR
Initialized
Initialized*
1
Initialized
P3ICR
Initialized
Initialized*
1
Initialized
P5ICR
Initialized
Initialized*
1
Initialized
P6ICR
Initialized
Initialized*
1
Initialized
PAICR
Initialized
Initialized*
1
Initialized
PBICR
Initialized
Initialized*
1
Initialized
PCICR
Initialized
Initialized*
1
Initialized
PDICR
Initialized
Initialized*
1
Initialized
PEICR
Initialized
Initialized*
1
Initialized
PFICR
Initialized
Initialized*
1
Initialized
PORTH
PORTI
PORTJ
PORTK
PHDR
Initialized
Initialized*
1
Initialized
PIDR
Initialized
Initialized*
1
Initialized
PJDR
Initialized
Initialized*
1
Initialized
PKDR
Initialized
Initialized*
1
Initialized
I/O port
