background image
Section 15 Programmable Pulse Generator (PPG)
Rev. 2.00 Sep. 24, 2008 Page 783 of 1468
REJ09B0412-0200
• NDERH_1
Bit
Bit Name
Initial
Value
R/W
Description
7
6
5
4
3
2
1
0
NDER31
NDER30
NDER29
NDER28
NDER27
NDER26
NDER25
NDER24
0
0
0
0
0
0
0
0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Next Data Enable 31 to 24
When a bit is set to 1, the value in the corresponding
NDRH_1 bit is transferred to the PODRH_1 bit by the
selected output trigger. Values are not transferred from
NDRH_1 to PODRH_1 for cleared bits.
• NDERL_1
Bit
Bit Name
Initial
Value
R/W
Description
7
6
5
4
3
2
1
0
NDER23
NDER22
NDER21
NDER20
NDER19
NDER18
NDER17
NDER16
0
0
0
0
0
0
0
0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Next Data Enable 23 to 16
When a bit is set to 1, the value in the corresponding
NDRL_1 bit is transferred to the PODRL_1 bit by the
selected output trigger. Values are not transferred from
NDRL_1 to PODRL_1 for cleared bits.
