Section 17 32K Timer (TM32K)

Rev. 2.00 Sep. 24, 2008 Page 853 of 1468

REJ09B0412-0200

17.4

Interrupt Source

At the interrupt interval, the 32K timer generates a 32K timer-overflow interrupt (32KOVI) that

lasts for three cycles of the subclock. Since 32KOVI is internally connected to IRQ15, the IRQ15F

bit is set to 1 when an interrupt is generated. For the IRQ15 setting, select an interrupt request

generated at the falling edge with ISCR. For details, see section 7, Interrupt Controller.

The 32K timer operates in both software-standby and deep-software standby modes. Through

generation of the 32K timer interrupt, the timer can provide the trigger for release from software

standby and deep-software-standby modes. For details, see section 28, Power-Down Modes.

Table 17.2

TM32K Interrupt Source

Name

Interrupt Source

Interrupt Flag DTC Activation

Software Standby

Mode Reset

Deep Software

Standby reset

IRQ15F

Impossible

Possible

Impossible

32KOVI TCNT32K interrupt

DT32KIF

Impossible

Possible
