Section 20 USB Function Module (USB)

Rev. 2.00 Sep. 24, 2008 Page 985 of 1468

REJ09B0412-0200

20.3.20

FIFO Clear Register (FCLR)

FCLR is a register to initialize the FIFO buffers for each endpoint. Writing 1 to a bit clears all the

data in the corresponding FIFO buffer. Note that the corresponding interrupt flag is not cleared.

Do not clear a FIFO buffer during transfer.

Bit

Bit Name

Initial Value

R/W



Undefined



EP3 CLR

Undefined

EP1 CLR

Undefined

EP2 CLR

Undefined



Undefined



Undefined



EP0o CLR

Undefined

EP0i CLR

Undefined

Bit

Bit Name

Initial

Value

R/W

Description



Undefined



Reserved

The write value should always be 0.

EP3 CLR

Undefined

EP3 Clear

Writing 1 to this bit initializes the endpoint 3 transmit

FIFO buffer.

EP1 CLR

Undefined

EP1 Clear

Writing 1 to this bit initializes both sides of the

endpoint 1 receive FIFO buffer.

EP2 CLR

Undefined

EP2 Clear

Writing 1 to this bit initializes both sides of the

endpoint 2 transmit FIFO buffer.



Undefined



Reserved

The write value should always be 0.

EP0o CLR

Undefined

EP0o Clear

Writing 1 to this bit initializes the endpoint 0 receive

FIFO buffer.

EP0i CLR

Undefined

EP0i Clear

Writing 1 to this bit initializes the endpoint 0 transmit

FIFO buffer.
