The PEWCT1060 is a 20 dB WR-75 four port crossguide coupler with one coupled port terminated (making it a three

port coupler) and a coax adapter on the opposite coupled port. This coupler can be mounted directly into the waveguide

signal path, connected via coax to allow signal sampling /monitoring. The coupler has a typical VSWR of 1.05:1 and are

made of bronze with brass Square Cover flanges. The PEWCT1060 is part of a family of cross guide couplers offered by

Pasternack with coupling values ranging from 20 to 50 dB. There is also a full family of top wall (broad wall) couplers.

For the three port version of this coupler (terminated but no coax adapter) please see the PEWCT1016. For the four port

version of this coupler (no termination, no coax adapter) please see the PEWCP1051.

Features

• Three Port

• Crossguide Waveguide Coupler

• Terminated

• 20 dB Nominal Coupling Level

• SMA Female Coax Adapter

• 10 GHz to 15 GHz Frequency Range

• Waveguide Body made of Bronze with Brass Flanges

• Low VSWR

Applications

• Test Benches

• Radar

• Satellite

• Microwave Radio

• Attenuation Measurements

• Power Measurements

• Source Leveling

Electrical Specifications

Description

Minimum

Typical

Maximum

Units

Frequency Range

10

15

GHz

Impedance

50

Ohms

Coupler

Nominal Coupling Level

20

dB

Directivity

25

dB

Insertion Loss

0.1

dB

Main Line VSWR

1.05:1

Termination

Input Power (CW)

2.5

Watts

Waveguide to Coax Adapters

VSWR

1.25:1

.

Mechanical Specifications

.

Interface

Waveguide Size

WR-75

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: WR-75 Waveguide 20 dB Crossguide Coupler, Square Cover Flange, SMA Female Coupled

Port, 10 GHz to 15 GHz, Bronze PEWCT1060

PEWCT1060 REV 1.0

WR-75 Waveguide 20 dB Crossguide Coupler, Square Cover

Flange, SMA Female Coupled Port, 10 GHz to 15 GHz, Bronze

Waveguide Couplers Assemblies Technical Data

PEWCT1060
