background image
2017-01-30
1
2017-01-30
Power SIDELED
Datasheet
Version 1.2
LS B6SP
Power SIDELED features a compact package with a
wide brightness range and high luminous efficiency.
Power SIDELED verfügt über eine platzsparende
Bauform mit einer breiten Spanne an Helligkeit und
hoher Lichtausbeute.
Features:
Besondere Merkmale:
•
Package: white PLCC-2 package, clear silicone
resin
•
Gehäusetyp: weisses PLCC-2 Gehäuse, klarer
Silikon - Verguss
•
Technology: InGaAlP Thinfilm
•
Technologie: InGaAlP Thinfilm
•
Viewing angle at 50 % I
V: 120° (Lambertian
Emitter)
•
Abstrahlwinkel bei 50 % I
V: 120° (Lambertscher
Strahler)
•
Color: super red (630 nm)
•
Farbe: super rot (630 nm)
•
Optical efficiency (typ.): 74 lm/W (super red)
•
Optischer Wirkungsgrad (typ.): 74 lm/W (super
rot)
•
Corrosion Robustness: Improved corrosion
robustness
•
Korrosionsstabilität: Verbesserte
Korrosionsstabilität
Applications
Anwendungen
•
Exterior Automotive Lighting
•
Automobilbeleuchtung außen
