E5002_ESD-R-B • 9/14/2018

Fort Lauderdale, FL 33301 USA • 954-766-2800 • www.kemet.com

One world. One KEMET

EMI Cores

ESD-R-B Toroidal Cores for Round Cables

for Low & High Frequency (with snail-shaped case)

Benefits

• MnZn≤10MHz(AMbandrange)andNiZn≤300MHz

(FMbandrange)optionsavailable

• Solid construction

• Easy to install with one M4 screw

• UL94V–2flameretardantratedcase

Overview

The KEMET ESD-R-B series solid toroidal cores are

designedtouseonroundcables.Thewiderangeof

ManganeseZinc(MnZn)andNickelZinc(NiZn)options

allowsfortargetingofspecificfrequencyranges.The

snail-shapedcaseallowsfixingthecoreintheapplication

to avoid contact with other components.

EMIcoresarepartofafamilyofpassivecomponentswhich

addresstheissuesofnoiseorelectromagneticinterference

(EMI)incircuitsorsystems.

Applications

• Consumer electronics

• Air conditioners

• Power conditioners

• Refrigerators

• Washingmachines

• Industrialequipment

• Medicalequipment
