EMIF02-USB03F2
5/7
Figure 11: Order Code
Figure 12: FLIP-CHIP Package Mechanical Data
Figure 14: Foot Print Recommendations
Figure 15: Marking
EMIF
yy
-
xxx zz
Fx
EMI Filter
Number of lines
Information
Package
x = resistance value (Ohms)
z = capacitance value / 10(pF)
or
3 letters = application
2 digits = version
F = Flip-Chip
x
= 1: 500µm, Bump = 315µm
= 2: Leadfree Pitch = 500µm, Bump = 315µm
1.57mm ± 50µm
315µm ± 50
500µm ± 50
650µm ± 65
Copper pad Diameter :
250µm recommended, 300µm max.
Solder stencil opening :
330µm recommended
Solder mask opening recommendation :
340µm min. for 300µm copper pad diameter
E
x
y
x
w
z
w
565
400
Dot, ST logo
xx = marking
z = packaging location
yww = datecode
(y = year
ww = week)
All dimensions in µm
