AC-DC Power Supplies

1 of 1

Creation Date : January 21, 2019 (GMT)

ZWS150BP-48/R

Sales Region

Worldwide

Series

ZWS-BP

Status

Production

Feature

Peak Load

Peak power capability

Option

Remote ON/OFF control

Option Lineup

Please refer to here.

Recommended EMC Filter Please refer to here.

Accessories

Please refer to the catalog

Electrical Characteristics

Input Voltage Range[AC]

85 to 265V

Input Voltage Range[DC]

120 to 370V

Efficiency

90% Typ.

Rated Output Voltage[DC]

48V

Output Voltage Range[DC]

39.6 to 52.8V

Maximum Output Current

Maximum Average Current

3.2A

Maximum Peak Current

6.4A

Maximum Output Power

Maximum Average Power

153.6W

Maximum Peak Power

307.2W

Cases Shape & Size

Case’ｓ shape

PC board

Width(W)

75mm Nom.

Height(H)

37mm Nom.

Depth(D)

160mm Nom.

Weight

360g Typ.

Other

Operating Temp. Range

-10 to 70°C

Cooling

Convection cooling

Safety Standard(Certified)

UL60950-1

CSA C22.2 No.60950-1

EN60950-1

EN50178 (OV II)

Safety Standard(Conformed)

Den-an

Remarks

This page only shows representative characteristics. Please refer to the

technical data for detailed specifications and conditions.
