SEMICONDUCTOR

RoHS

RoHS

Nell High Power Products

Maximum junction operating and

storage temperature range

- 65 to180

ºC

0.25

K/W

Maximum thermal resistace,

junction to case

Maximum thermal resistance

case to heatsink

0.45

15

0.53

(lbf · in)

N · m

Maximum allowable mounting torque

Approximate weight

Case style

DO-203AB (DO-5)

T

(lbf · in)

N · m

g

oz.

Mounting surface, smooth, flat and greased

DC operation

See dimensions - link at the end of datasheet

CONDUCTION ANGEL

SINUSOIDAL CONDUCTION

RECTANGULAR CONDUCTION

UNITS

TEST CONDUCTIONS

K/W

180˚

120˚

90˚

60˚

30˚

0.08

0.10

0.13

0.19

0.30

0.06

0.11

0.14

0.20

0.30

• The table above shows the increment of thermal resistance RthJC when devices operate at different conduction angles than DC

Note

70D(R)Series

PARAMETER

SYMBOL

UNIT

TEST CONDITIONS

02 TO 12

16

- 65 to150

(1)

Not lubricated thread ,tighting on nut

Lubricated thread ,tighting on hexagon

(2)

Lubricated thread ,tighting on nut

(1)

Not lubricated thread ,tighting on hexagon

(2)

3.4(30)

2.3(20)

4.2(37)

3.2(28)

(+0% , -10%)

Note

(1) Recommended for pass-through holes.

(2) Recommended for holed threaded heatsinks.

70D(R)

THERMAL AND MECHANICAL SPECIFCATIONS

FORWARD CONDUCTION

PARAMETER

SYMBOL

UNIT

TEST CONDITIONS

Maximum average forward current

at case temperature

180° conduction, half sine wave

Maximum RMS forward current

A

ºC

110

Maximum peak, one-cycle forward,

non-reptitive surge current

t = 10ms

t = 8.3ms

t = 10ms

t

t = 10ms

t = 8.3ms

t = 10ms

t = 8.3ms

No voltage

reapplied

reapplied

No voltage

reapplied

reapplied

2

I t

Sinusoidal half wave,

1200

1250

1000

1050

7200

6540

5070

4610

2

A s

A

A

72000

t = 0.1 to 10 ms, no voltage reapplied

2

I √t

Maximum l²t for fusing

Maximum l²√t for fusing

Maximum forward voltage drop

1.35

2

V

02 TO 12

16

70

70

140

110

1.46

70D(R)
