TAPE AND REEL INFORMATION
*All dimensions are nominal
Device
Package
Type
Package
Drawing
Pins
SPQ
Reel
Diameter
(mm)
Reel
Width
W1 (mm)
A0
(mm)
B0
(mm)
K0
(mm)
P1
(mm)
W
(mm)
Pin1
Quadrant
BQ27Z561YPHR-R1
DSBGA
YPH
12
3000
180.0
8.4
1.83
2.2
0.53
4.0
8.0
Q1
PACKAGE MATERIALS INFORMATION
www.ti.com
27-Apr-2019
Pack Materials-Page 1
