1 / 6 page  Technical Data 10449 Effective October 2015 FP1108L3 and FP1108L4 High frequency, high current power inductors Description • High current carrying capacity • Ultra low DCR • Low core loss • Operating frequency − L3 version 500kHz-800kHz − L4 version 1MHz-3MHz • Inductance range from 105nH to 180nH • Current range from 33 to 57 amps • 11.0 x 8.0mm footprint surface mount package in an 8.0mm heightt • Ferrite core material • Halogen free, lead free, RoHS compliant Applications • Servers • Multi-phase and Vcore regulators • Voltage Regulator Modules (VRMs) • Desktop VRMs and EVRDs • Data networking and storage systems • Graphics cards and battery power systems • Point-of-Load modules Environmental Data • Storage temperature range (Component): -40°C to +125°C • Operating temperature range: -40°C to +125°C (ambient + self-temperature rise) • Solder reflow temperature: J-STD-020D compliant Pb HALOGEN HF FREE |
