1 / 4 page

Technical Data 10530

Effective April 2016

Product description

•

High breaking capacity and I²t

•

High surge withstand: 20 cycles of 1.2/50 μs -

8/20 μs, 20 kV/10 kA surge

•

UL248-14 compliant

•

Ceramic tube, nickel plated brass end cap

•

6.3 mm x 32 mm form factor

•

Ferrule and axial lead options

•

Halogen free, lead free, RoHS compliant

Applications

Primary circuit protection:

•

Lighting controls

•

Surge protectors

•

LED and general lighting

Agency information

•

cURus Recognition file number: E19180, Vol 7

Ordering

•

Use ordering number (see page 3 for details)

Packaging suffixes

•

BK (100 parts per carton)

•

TR (500 parts per roll)

MDH-R

6.3 mm x 32 mm Ferrule and axial lead, high breaking

capacity, high I2t ceramic tube fuses

Pb

HALOGEN

HF

FREE
