Crystalfontz
CFAL1602C Series OLED Display Module
www.crystalfontz.com
Datasheet Release Date 2017-08-28
Page | 9
11. Optical Characteristics
CFAL1602C-B and CFAL1602C-PB
Item
Symbol
Condition
Min
Typ
Max
Unit
View Angle
(V)
θ
-
160
-
-
deg
(H)
φ
-
160
-
-
Contrast Ratio
CR
Dark
2000:1
-
-
deg
Response Time
T rise
-
-
10
-
μs
T fall
10
Display with 50% Check Board Brightness
60
70
-
cd/m2
CIEx (Blue)
(CIE1931)
0.12
0.16
0.20
-
CIEy (Blue)
(CIE1931)
0.19
0.23
0.27
-
CFAL1602C-G and CFAL1602C-PG
Item
Symbol
Condition
Min
Typ
Max
Unit
View Angle
(V)
θ
-
160
-
-
deg
(H)
φ
-
160
-
-
Contrast Ratio
CR
Dark
2000:1
-
-
deg
Response Time
T rise
-
-
10
-
μs
T fall
10
Display with 50% Check Board Brightness
120
150
-
cd/m2
CIEx (Green)
(CIE1931)
0.24
0.28
0.32
-
CIEy (Green)
(CIE1931)
0.59
0.63
0.67
-
CFAL1602C-GT and CFAL1602C-PGT
Item
Symbol
Condition
Min
Typ
Max
Unit
View Angle
(V)
θ
-
160
-
-
deg
(H)
φ
-
160
-
-
Contrast Ratio
CR
Dark
2000:1
-
-
deg
Response Time
T rise
-
-
10
-
μs
T fall
10
Display with 50% Check Board Brightness
120
150
-
cd/m2
CIEx (Green)
(CIE1931)
0.24
0.28
0.32
-
CIEy (Green)
(CIE1931)
0.59
0.63
0.67
-
