IS25LP032D

IS25WP032D

Integrated Silicon Solution, Inc.- www.issi.com

Rev. A12

08/04/2020

9. ELECTRICAL CHARACTERISTICS

9.1 ABSOLUTE MAXIMUM RATINGS (1)

Storage Temperature

-65°C to +150°C

Input Voltage with Respect to Ground on All Pins

-0.5V to VCC + 0.5V

All Output Voltage with Respect to Ground

-0.5V to VCC + 0.5V

VCC

IS25LP

-0.5V to +6.0V

IS25WP

-0.5V to +2.5V

Electrostatic Discharge Voltage (Human Body Model)(2)

-2000V to +2000V

Notes:

Applied conditions greater than those listed in “Absolute Maximum Ratings” may cause permanent damage to the

device. This is a stress rating only and functional operation of the device at these or any other conditions above

those indicated in the operational sections of this specification is not implied. Exposure to absolute maximum

rating conditions for extended periods may affect reliability.

2. ANSI/ESDA/JEDEC JS-001

9.2 OPERATING RANGE

Operating Temperature

Extended Grade E

-40°C to 105°C

Automotive Grade A3

-40°C to 125°C

VCC Power Supply

IS25LP

2.3V (VMIN)

– 3.6V (VMAX); 3.0V (Typ)

IS25WP

1.65V (VMIN)

–1.95V (VMAX); 1.8V (Typ)
