MODEL: JRQ2

JRQ2 SPECIFICATIONS

ES-1576 Rev.8 Page 4/5

http://www.m-system.co.jp/

EXTERNAL VIEW

3

2

1

2

3

4

5

6

7

8

1

2

3

4

5

6

7

8

1

2

3

4

5

6

7

8

ON

SW1

SW3

SW2

Span Adj.

Detecting Level Adj.

Detecting Level Adj. Pin

Pulse Amplitude Selector

Input Type Selectors

Zero Adj.

Sensor Excitation Adj.

Modular Jack

Input Monitor LED PL1

Input Monitor LED PL2

Refer to the instruction manual for detailed procedures.

OPERATION

rev. 30 counts

fwd. 100 counts

4mA

20mA

rev. 100 counts

fwd. 100 counts

–10V

+10V

OUTPUT

0

+

–

FORWARD

OPEN

REVERSE

REVERSE

STOP

FORWARD

RESET

STOP

min. 500 msec.

CLOSE

B

A INPUT

INPUT

Pulse counts are added or subtracted according to the rotary encoder’s rotating directions.

The counts are added when Phase A leads Phase B by 90 degrees (Forward rotation), and

subtracted when Phase A lags behind Phase B by 90 degrees (Reverse rotation).

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

50 (1.97)

72 (2.83)

107 (4.21)

136 (5.35)

[3.3 (.13)]

60 (2.36)

72 (2.83)

7.8 (.31)

CLAMP

(top & bottom)

DIN RAIL

35mm wide

2–4.5 (.18) dia.

MTG HOLE

25 (.98) deep

14–M3.5

SCREW

• When mounting, no extra space is needed between units.

12

5

6

14

11

1

10

15

4

3

2

7

9

8
