MODEL: M3SXT

M3SXT SPECIFICATIONS

ES-7702 Rev.6 Page 4/4

http://www.m-system.co.jp/

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

7

8

5

6

1

2

3

4

12

(.47)

110.5 (4.35)

[5 (.20)]

• When mounting, no extra space is needed between units.

DIN RAIL

35mm wide

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

Isolation

Digital

Computation

Output

Driver

+

–

OUTPUT

POWER LED

Low Drift

Amplifier

STATUS LED

CONFIGURATOR

JACK

DIP SW

3

4

6

7

8

5

1

2

+

–

T/C

comp. leadwire

+

–

CJC

SENSOR

U(+)

V(–)

POWER
