MODEL: W5RS

W5RS SPECIFICATIONS

ES-8509 Rev.9 Page 3/3

http://www.m-system.co.jp/

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

5

4

3

2

1

11

10

9

8

7

6

45 (1.77)

41 (1.61)

[3.3 (.13)]

• When mounting, no extra space is needed between units.

DIN RAIL

35mm wide

5–M3.5 SCREW

7.4 (.29)

6–M3 SCREW

6 (.24)

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

A

B

B

2

1

5

4

RTD

3

S

Z

Voltage

Amplifier

Burnout

Linearizer

Constant

Current

Differential

Amplifier

+

–

Reference

Resistor

U(+)

V(–)

POWER

10

11

+

–

OUTPUT 1

+

–

Isolation

Output

Driver

S

Z

Output

Driver

OUTPUT 2

6

7

8

9

Note 1: The section enclosed by broken line is only with 2nd output option.

Note 2: DO NOT connect to the terminals 1 – 2.

Specifications are subject to change without notice.
