MODEL: 40DR

40DR SPECIFICATIONS

ES-9533 Rev.10 Page 5/6

https://www.m-system.co.jp/

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

92 (3.62)

85 (3.35)

11

(.43)

96 (3.78)

96 (3.78)

103 (4.06)

10–M3 SCREW

TERMINALS

■ TOP VIEW

■ FRONT VIEW

■ SIDE VIEW

■ REAR VIEW

1

2

3

4

5

6

7

8

9

10

6.4 (.25)

12 (.47)

MOUNTING REQUIREMENTS unit: mm

92

+ 0.8

– 0

min. 120

Panel thickness: 1.6 to 8.0 mm
