2SC945

Low Frequency Amplifier

NPN Epitaxial Silicon Transistor

Document No.: F51939M

27-NOV-2021 V 2.0

www.futurewafer.com.tw

FQE-001-04

1/7

1. Synopsis

1-1. Feature List

●

BV CEO: 50V (Min.)

●

Low Saturation Voltage V CE(sat) < 0.3V @ 0.1A

●

I C = 400mA Continuous Collector Current

●

Complementary to 2SA733

1-2. Mechanical Characteristics

●

Molded JEDEC Package: TO-92

●

Packing: Tape Box

●

Flammability rating UL 94V-0

●

Halogen Free

●

JEDEC MSL Classification: LEVEL 1

1-3. Device Characteristics

1-4. Classification of h FE

B

C

E

TO-92

Device Symbol
