Product data sheet

Specifications

NEMA Contactor, Type S, reversing,

Size 1, 27A, 2 pole, single phase,

horizontal, 220/240 VAC 50/60 Hz

coil, open style

8702SCO2V03

Product availability : Stock - Normally stocked in distribution

facility

Price* : 1,139.00 USD

Main

Product Type

Contactor

Product Range

Type S

Contactor Type

Reversing

Complementary

NEMA Size

1

Rated Current

27 A

Number of Poles

2P

Mounting Orientation

Horizontal

Wiring Mode

3 wires

Maximum Voltage Rating

600 V AC

Phase

1 phase

Horsepower Rating

3 HP 230 V AC

2 HP 115 V AC

Coil Voltage

220 V AC 50 Hz

240 V AC 60 Hz

Control Circuit Type

Common control circuit

Control Units

No control units

Other Equipment

Fuse not supplied

Terminal Type

Screw clamp terminals

Height

5.00 in (127 mm)

Width

7.13 in (181 mm)

Depth

5.31 in (135 mm)

Environment

Enclosure Type

Not rated (open device)

Certifications

CSA

UL Listed

*  Price is “List Price” and may be subject to a trade discount – check with your local distributor or retailer for actual price.

May 19, 2022
