background image
isc website：www.iscsemi.com
isc & iscsemi is registered trademark
1
Ultrafast Rectifier
ISCN1730
FEATURES
·
Super fast switching for high efficiency
·
Low reverse leakage.
·
High forward surge current capability.
·
Minimum Lot-to-Lot variations for robust device
performance and reliable operation
APPLICATIONS
·
Mainly used in switching power supply, PWM pulse
width modulator,inverter as a freewheeling and other
electronic circuits, high-frequency rectifier diode, diode
or damping diode use
ABSOLUTE MAXIMUM RATINGS(Ta=25℃)
SYMBOL
PARAMETER
VALUE
UNIT
VRRM
Peak Repetitive Reverse Voltage
600
V
IF(AV)
Average Rectified Forward Current
60
A
IFSM
Non-repetitive Peak Surge Current
250
A
TJ
Max.Junction Temperature
175
℃
Tstg
Storage Temperature Range
-40~150
℃
THERMAL CHARACTERISTICS
SYMBOL
PARAMETER
MAX
UNIT
Rth j-c
Thermal Resistance,Junction to Case
0.5
℃
/W
