Molding Power Choke

CSHB0421 Series

This product is not authorized for use in any application related to safety.

Specification subject to change without notice. Please check web site for latest information.

Revised: 07/14/2020

Outline

:

▪ Magnetic shielded structure:excellent resistance to electro

Magmetic interference (EMI)

▪ A composite structure,ultra low buzz noise

▪ Low loss,high efficiency,wide application frequency

▪ Lightweight design,save space,suitable for high density SMT

Features：

▪ Core material: Alloy powder

▪ Core and winding loss:

See www.codaca.com/en/PowerInductorLossComparison

▪ Enviromental:RoHS,Reach compliant ,Halogen free

▪ Weight:0.23g

▪ Moisture Sensitivity:Level (MSL) 1

(unlimited floor life at 5

～40℃, RH≤ 70% relative humidity).

▪ Operating temperature range: -40℃～+125℃

(including coil

’s self temperature rise)

▪ Storage temperature range: -40℃～+125℃

Application：

▪ PDA/notebook/desktop/server applications

▪ DC /DC converters for entertainment/navigations systems

▪ Noise suppresion for motors:windshield wipers/power seats/Power

Mirrors/heating and ventilation blower/ HID lighting

1 Electrical Characteristics

2 Product Dimensions (mm)

Part No.

Inductance

(

μH)※1

D.C.R. (m

Ω)

Isat

(A)

※2

Irms

(A)

※3

0.15Max.

4.4±0.35

4.2±0.2

1.9±0.2

2.0±0.3

2.5

0.8±0.3

1.0

1

2

（2.5）

（1.5）

（3.7）(4.4)

(4.4)

±20%

Typical

Max.

Typical

CSHB0421-2R2M

2.20

25.1

29.5

5.50

CSHB0421-3R3M

3.30

33.4

36.8

5.00

CSHB0421-4R7M

4.70

49.7

58.5

4.50

CSHB0421-5R6M

5.60

60.5

71.1

4.00

CSHB0421-6R8M

6.80

78.7

92.5

3.50

CSHB0421-8R2M

8.20

101

118

3.00

CSHB0421-100M

10.0

110

129

2.50

All data is tested on 25

℃ ambient temperature

1.Inductance measure condition at 100kHz,1.0V

2.Isat:the actual value of DC current when the inductance decrease 30% of its initial value

3.Irms:the actual value of DC current when the temperature rise is

ΔT40℃(Ta=25℃)

3 How to order:

CSHB0421-3R3M

Model

Dimensions

Value Code

Typical Pad Layout
