Electrical ratings

S2000AF

2/8

1

Electrical ratings

Table 2.

Thermal data

Table 1.

Absolute maximum rating

Symbol

Parameter

Value

Unit

1500

V

700

V

9

V

Collector current

8

A

15

A

Base current

4

A

50

W

Insulation withstand voltage (RMS) from all three leads to

external heatsink

2500

V

Storage temperature

-65 to 150

°C

Max. operating junction temperature

150

Symbol

Parameter

Value

Unit

2.5

°C/W
