CUI DEVICES | SERIES: PR19 | DESCRIPTION: POWER RELAY
date 08/09/2022 | page 3 of 5
cuidevices.com
24.6±0.3
2-0.5±0.1
1.1±0.1
16.4±0.3
1.1±0.1
3.5±0.3
4.0±0.3
4-0.5±0.1
7.5±0.3
10.6±0.3
16.4±0.1
3.5±0.1
2.6±0.3
4-O1.3+0.1
0
MECHANICAL DRAWING
units: mm
tolerance: ±0.3 mm
unless otherwise noted
Recommended PCB Layout
Bottom View
Wiring Diagram
Bottom View
ITEM DESCRIPTION
MATERIAL
PLATING/COLOR
A
housing
PBT (UL94V-0)
black
B
terminals
copper covered
steel
tin
Additional Resources: Product Page
