B65646-A-R27 Datasheet(PDF) 1 Page - EPCOS |
|
|
|||||||||||||||||||||||||||||
B65646-A-R27 Datasheet(HTML) 1 Page - EPCOS |
|
|
1 / 4 page  259 08/01 I In accordance with IEC 61247 I Particularly suitable for power transformers and energy storage chokes I PM cores are supplied in sets Magnetic characteristics (per set) Σl/A = 0,227 mm–1 le = 84 mm Ae = 370 mm2 Amin = 280 mm2 Ve = 31 000 mm3 Approx. weight 140 g/set Gapped Ungapped Material AL value nH s approx. mm µe Ordering code N27 250 ± 3 % 2,00 45 B65646-A250-A27 630 ± 3 % 0,63 114 B65646-A630-A27 Material AL value nH µe AL1min nH PV W/set Ordering code N27 7400 + 30/– 20 % 1330 5000 4,2 (200 mT, 25 kHz, 100 °C) B65646-A-R27 N87 7400 + 30/– 20 % 1330 5000 15,5 (200 mT, 100 kHz, 100 °C) B65646-A-R87 B65646 PM 50/39 through PM 114/39 Core PM 50/39 |
