background image
Pressure gauge
MA-23-10-R1/8
Part number: 183897
General operating condition
Data sheet
Feature
Value
Display range
0 bar ... 10 bar
Display range
0 psi ... 145 psi
Symbol
00991463
Pressure gauge nominal size
23
Structural design
Bourdon tube pressure gauge
Type of mounting
Line installation
Operating medium
Inert gas
Neutral liquids
Operating pressure
0 MPa ... 1 MPa
Operating pressure
0 bar ... 10 bar
Operating pressure
0 psi ... 145 psi
Intermittent load factor
0.6
Measurement accuracy class
4
Degree of protection
IP44
Temperature of medium
-20 °C ... 60 °C
Ambient temperature
-20 °C ... 60 °C
LABS (PWIS) conformity
VDMA24364-B1/B2-L
Note on materials
RoHS-compliant
Connection position
Centered on rear side
Pneumatic connection
R1/8
Materials in contact with the media
Brass
Material of screwed plug
Brass
Housing material
Brass
Inspection window material
PC
Housing colour
Black
Product weight
27 g
Information on operating and pilot media
No acetylene
No oxygen
Scale
Double scale
bar (außen)
psi (internal)
7/15/24 - Subject to change - Festo SE & Co. KG
1/1
