ADN4600
Data Sheet
Rev. C | Page 8 of 28
TYPICAL PERFORMANCE CHARACTERISTICS
Figure 5 to Figure 8 were obtained using the standard test circuit shown in Figure 4.
50Ω CABLES
2
2
HIGH SPEED
SAMPLING
OSCILLOSCOPE
50Ω CABLES
2
2
50Ω
ADN4600
AC-COUPLED
EVALUATION
BOARD
INPUT
PIN
OUTPUT
PIN
PATTERN
GENERATOR
DATA OUT
TP2
TP1
Figure 4. Standard Test Circuit (No Channel)
50ps/DIV
Figure 5. 3.25 Gbps Input Eye
(TP1 from Figure 4)
50ps/DIV
Figure 6. 4.25 Gbps Input Eye
(TP1 from Figure 4)
50ps/DIV
Figure 7. 3.25 Gbps Output Eye, No Channel
(TP2 from Figure 4)
50ps/DIV
Figure 8. 4.25 Gbps Output Eye, No Channel
(TP2 from Figure 4)
