ADA4939-1/ADA4939-2

Data Sheet

Rev. A | Page 2 of 24

TABLE OF CONTENTS

Features .............................................................................................. 1



Applications....................................................................................... 1



General Description ......................................................................... 1



Functional Block Diagrams............................................................. 1



Revision History ............................................................................... 2



Specifications..................................................................................... 3



5 V Operation ............................................................................... 3



3.3 V Operation ............................................................................ 5



Absolute Maximum Ratings............................................................ 7



Thermal Resistance ...................................................................... 7



Maximum Power Dissipation ..................................................... 7



ESD Caution.................................................................................. 7



Pin Configurations and Function Descriptions ........................... 8



Typical Performance Characteristics ............................................. 9



Test Circuits..................................................................................... 15



Operational Description................................................................ 16



Definition of Terms.................................................................... 16



Theory of Operation ...................................................................... 17



Analyzing an Application Circuit ............................................ 17



Setting the Closed-Loop Gain .................................................. 17



Stable for Gains ≥2 ..................................................................... 17



Estimating the Output Noise Voltage ...................................... 17



Impact of Mismatches in the Feedback Networks................. 18



Calculating the Input Impedance for an Application Circuit

....................................................................................................... 19



Input Common-Mode Voltage Range ..................................... 21



Input and Output Capacitive AC Coupling............................ 21



Minimum RG Value of 50 Ω ...................................................... 21



Setting the Output Common-Mode Voltage .......................... 21



Layout, Grounding, and Bypassing.............................................. 22



High Performance ADC Driving ................................................. 23



Outline Dimensions ....................................................................... 24



Ordering Guide .......................................................................... 24



REVISION HISTORY

5/2016—Rev. 0 to Rev. A

Changed ADA4939 to ADA4939-1/ADA4939-2, CP-16-2 to

CP-16-21, and CP-24-1 to CP-24-10........................... Throughout

Changes to Figure 5, Figure 6, Table 9, and Table 10................... 8

Changes to Figure 54...................................................................... 23

Updated Outline Dimensions ....................................................... 24

Changes to Ordering Guide .......................................................... 24

5/2008—Revision 0: Initial Version
