H-76

TZN/TZ Series

Dimensions

TZ4SP

TZ4ST

TZ4M

※Since TZ4SP uses same identification plate with TZ4ST, the lamp does not work even though it has a EV2 output signal lamp.

48

15

12

80

Min. 55

45+0.60

Min. 74

68+0.70

12

95

48

72

100

13

● Panel cut-out

● Panel cut-out

TZ4H

TZN4H

48

48

90

13

Min. 50

45+0.60

● Panel cut-out

TZ4W

TZN4W

108

96

108

96

100

13

Min. 112

92+0.80

● Panel cut-out

(unit: mm)

<Bracket>
