1 / 2 page  Schottky Barrier Diode DF10SC4M www.iscsemi.com 1 FEATURES · Low VF · High Recovery Speed · SMD APPLICATIONS · PFC · AC/DC Section of SMPS · Choppers Motor Drives ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE UNIT VRRM VRWM VR Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage 40 V IF(AV) Average Rectified Forward Current 5×2 A IFSM Non-repetitive Peak Surge Current (50Hz sine, I cycle) 100 A TJ Max. Junction Temperature 150 ℃ Tstg Storage Temperature Range -40~150 ℃ THERMAL CHARACTERISTICS SYMBOL PARAMETER MAX UNIT Rth j-c Thermal Resistance,Junction to Case 3.0 ℃ /W 2 2 3 1 |
