EVSK-002 Power Inductor Sample Kit

MPL-AY Molded Inductor Series,

Sizes 3020/4020

EVSK-002 Rev. 1.0

MonolithicPower.com

1

3/17/2022

MPS Proprietary Information. Patent Protected. Unauthorized Photocopy and Duplication Prohibited.

© 2022 MPS. All Rights Reserved.

Order Code

L (µH)

RDC (mΩ)

IR (A)

ISAT (A)

Units

MPL-AY3020-R47

0.47

19.5

6.3

9

15

MPL-AY3020-R68

0.68

26

5.15

8.6

15

MPL-AY3020-R82

0.82

28

4.7

8

15

MPL-AY3020-1R0

1.0

30

4.3

6.2

15

MPL-AY3020-1R5

1.5

35

3.4

5.9

15

MPL-AY3020-2R2

2.2

64

3.0

5.3

15

MPL-AY3020-3R3

3.3

121

2.5

3.7

15

MPL-AY3020-4R7

4.7

173

2.0

3.1

15

MPL-AY3020-5R6

5.6

209

1.8

2.8

15

MPL-AY3020-6R8

6.8

250

1.65

2.6

15

MPL-AY3020-8R2

8.2

345

1.4

1.95

15

MPL-AY3020-100

10

370

1.3

1.75

15

MPL-AY4020-5R6

5.6

97

2.45

2.6

15

MPL-AY4020-6R8

6.8

129

2.2

2.4

15

MPL-AY4020-8R2

8.2

136

2.1

2.1

15

MPL-AY4020-100

10

163

1.9

2

15

DESCRIPTION

The MPL-AY series offers low DCR and ACR, as well as

the ability to handle high currents.

FEATURES

• Low Audible Noise

• Molded Construction

• Soft Saturation

• Stable across High Temperatures

• Low DCR

• RoHS/REACH-Compliant, Halogen-Free

INCLUDED IN THIS SAMPLE KIT

APPLICATIONS

• Battery-Powered Devices

• High Switching Frequency SMPS

• High-Current SMPS

• POL Converters

• Portable Devices

• Input Filters

All MPS parts are lead-free, halogen-free, and adhere to the RoHS directive. For MPS green status, please visit the MPS website under Quality Assurance.
