EXAMPLE STENCIL DESIGN

(2.6)

2X (0.9)

2X (0.5)

(R0.05) TYP

SOT(SOD-323) - 1 mm max height

DYF0002A

SMALL OUTLINE TRANSISTOR

4228484/C 12/2024

NOTES: (continued)

5. Laser cutting apertures with trapezoidal walls and rounded corners may offer better paste release. IPC-7525 may have alternate

design recommendations.

6. Board assembly site may have different recommendations for stencil design.

SOLDER PASTE EXAMPLE

BASED ON 0.125 mm THICK STENCIL

SCALE:25X

PKG

PKG

1

2
