RATINGS:

Volts: 600VAC, 300VDC

Amps: 1/4 to 30A

IR: 200kA I.R. AC,

100kA I.R. DC

APPLIC ATIONS:

•

Small motors

•

Contactors

•

Lighting, heating &

general loads

•

Branch circuit protection

Note: See motor fuse applications

tables for more information

APPRO VALS:

•

UL listed to standard

248-4 File E2137

•

CSA certified to standard

C22.2 No. 248.4

•

DC listed to UL standard

248

Amp-Trap 2000® ATDR small-dimension fuses can provide IEC Type 2

No Damage protection to your facility’s increasingly sensitive branch

circuit components and small motors – minimizing the risk of fault-

related damage. ATDR Class CC fuses deliver the best time-delay

characteristics in their class with excellent cycling ability for small

motor loads.

FEATURES/BENEFIT S:

•

Time-delay for motor starting inrush currents without nuisance

opening

•

Highly current-limiting for low peak let-thru current

•

Improved cycling ability for frequent motor starts/stops without

nuisance fuse opening

•

Rejection-style design prevents replacement errors (when used

with recommended fuse blocks)

•

High-visibility orange label ensures instant brand recognition,

simplifies replacement

•

Metal-embossed date and catalog number for traceability and

lasting identification

•

Fiberglass body provides dimensional stability in harsh industrial

settings

•

High-grade silica filler ensures fast arc quenching and optimum

current-limitation

ATDR

Time Delay/Class CC

UL/CSA LISTED POWER FUSES

THE BEST PROTECTION FOR TODAY’S SMALL MOTORS
