IS25LE512MG

IS25WE512MG

Integrated Silicon Solution, Inc.- www.issi.com

Rev. A6

10/02/2025

Table 5.4 JEDEC Basic Flash Parameter Table (Continued)

Description

Address

(Byte)

Address

(Bit)

Data

Multiplier from typical time to maximum time for page or byte

PROGRAM, 2* (Count+1), 6.67

58h

3:0

0011b

Page size, 2^N bytes

7:4

1000b

(1001b(1))

Page Program Typical time, (Count+1) * units,

300/2000us(600/4000us)

5Ah:59h

12:8

00100b

(01001b(1))

Units (0b:8us, 1b:64us)

Byte Program Typical time, first byte, (Count+1) * units, 10/70us

17:14

1001b

Units, 0b:1us, 1b:8us

Byte Program Typical time, additional byte, (Count+1) * units,

(tPP-tBP)/255, 1.14us

22:19

0001b

Units (0b:1us, 1b:8us)

Chip Erase, Typical time, (Count+1) * units, 140/360s

5Bh

28:24

00010b

Units (00b:16ms, 01b:256ms, 10b:4s, 11b:64s)

30:29

11b

Reserved

Prohibited Operations During Program Suspend

5Ch

3:0

1100b

Prohibited Operations During Erase Suspend

7:4

1110b

Reserved

5Eh:5Dh

Program Resume to Suspend Interval, (Couint+1) * 64us, 80us

12:9

0001b

Suspend in-progress program max latency, (Count+1) * units, 100us

17:13

01100b

Units (00b:128ns, 01b:1us, 10b:8us, 11b:64us)

19:18

10b

Erase Resume to Suspend Interval, (Couint+1) * 64us, 80us

23:20

0001b

Suspend in-progress erase max latency, (Count+1) * units, 100us

5Fh

28:24

01100b

Units (00b:128ns, 01b:1us, 10b:8us, 11b:64us)

30:29

10b

Suspend /Resume supported

Program Resume Instruction

60h

7:0

7Ah

Program Suspend Instruction

61h

15:8

75h

Resume Instruction

62h

23:16

7Ah

Suspend Instruction

63h

31:24

75h

Reserved

64h

1:0

11b

Status Register Polling Device Busy

7:2

111101b

Note:

Only for option K (512B Page Size instead of 256B)
