SN74LS592DR Datasheet(PDF) 21 Page - Texas Instruments

Part # SN74LS592DR
Description  8-BIT BINARY COUNTERS WITH INPUT REGISTERS
PDF  30 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Manufacturer  TI [Texas Instruments]
Direct Link  http://www.ti.com
Logo TI - Texas Instruments

SN74LS592DR Datasheet(HTML) 21 Page - Texas Instruments

Back Button SN74LS592DR Datasheet HTML 17Page - Texas Instruments SN74LS592DR Datasheet HTML 18Page - Texas Instruments SN74LS592DR Datasheet HTML 19Page - Texas Instruments SN74LS592DR Datasheet HTML 20Page - Texas Instruments SN74LS592DR Datasheet HTML 21Page - Texas Instruments SN74LS592DR Datasheet HTML 22Page - Texas Instruments SN74LS592DR Datasheet HTML 23Page - Texas Instruments SN74LS592DR Datasheet HTML 24Page - Texas Instruments SN74LS592DR Datasheet HTML 25Page - Texas Instruments Next Button
Zoom Inzoom in Zoom Outzoom out
 21 / 30 page
background image
*All dimensions are nominal
Device
Package Type
Package Drawing
Pins
SPQ
Length (mm)
Width (mm)
Height (mm)
SN74LS592DR
SOIC
D
16
2500
343.0
346.0
29.0
SN74LS592NSR
SO
NS
16
2000
346.0
346.0
33.0
SN74LS593DWR
SOIC
DW
20
2000
346.0
346.0
41.0
PACKAGE MATERIALS INFORMATION
www.ti.com
28-Feb-2008
Pack Materials-Page 2
