153-5-R1 Datasheet(PDF) 1 Page - Howard Butler Ltd |
|
|
|||||||||||||||||||||||||||||
153-5-R1 Datasheet(HTML) 1 Page - Howard Butler Ltd |
|
|
1 / 2 page  DESCRIPTION Two small moulded case current transformers suitable for primary currents from 1A to 500A using cable or bar primaries APPLICATION For use where space is limited within the panel, and where a built in choice of fixing methods is required. 15 SERIES MOULDED CASE CURRENT TRANSFORMERS FEATURES • Three built in fixing methods - Base, Din Rail & Busbar mounting • Built in hinged terminal cover • Terminals suitable for screw or push on connectors • Small size enables mounting where busbars run close together • Case moulded in high impact polyester • Secondary terminals with double layout • Primary ranges from 1A to 500A TECHNICAL OVERVIEW • Conforms to IEC 44-1 / IEC 185, BS 7626 • Insulation level 0.72/3kV • Ambient temperature range -20º to 70ºc • Self extinguishing to UL94VO • Enclosure to IP20 • CE approved • Manufactured to ISO 9002 DIN rail mounting Base mounting Hinged terminal cover Busbar mounting 11840 |
