cylindrical cartridge fuses

HRC

For other ratings and types

Contact us on +44 (0) 845 605 4333

With a high breaking capacity

to suit industrial applications

Neutral links

10

0123 00

8 x 32

10

0133 00 10 x 38

10

0143 00 14 x 51

10

0153 00 22 x 58

Note : Numbers refer to physical size of fuse i.e. 10 x 38 means

Ø 10 mm x 38 mm length

Fuses with strikers are available on special request in specific ratings

Minimum pack quantities apply

Dimensions (p. 95)

0123 12

0123 04

0153 96

0143 10

Type gG

Conform to BS EN 60269-1, IEC 60269-1

Bureau Veritas approved

Rating

Voltage ±

Breaking

Without

(Amps)

(Volts)

capacity (Amps)

indicator

8 x 32

10

0123 01

1

10

0123 02

2

10

0123 04

4

10

0123 06

6

10

0123 08

8

400

20 000

10

0123 10

10

10

0123 12

12

10

0123 16

16

Pack

Cat. Nos.

Type gG industrial

HRC (high rupturing capacity)

Conform to BS EN 60269-1 and 2 (BS 88)

IEC 60269-1, 2 and 2-1

Bureau Veritas approved

Rating

Voltage ±

Breaking

Without

(Amps)

(Volts)

capacity (Amps)

indicator

10 x 38

10

0133 94

0·5

10

0133 01

1

10

0133 02

2

10

0133 04

4

10

0133 06

6

500

100 000

10

0133 08

8

10

0133 10

10

10

0133 12

12

10

0133 16

16

10

0133 20

20

10

0133 25

25

Without

striker

14 x 51

10

0143 02

2

10

0143 04

4

10

0143 06

6

10

0143 10

10

10

0143 16

16

500

100 000

10

0143 20

20

10

0143 25

25

10

0143 32

32

10

0143 40

40

10

0143 50

50

Without

striker

22 x 58

10

0153 10

10

10

0153 16

16

10

0153 20

20

10

0153 25

25

500

100 000

10

0153 32

32

10

0153 40

40

10

0153 50

50

10

0153 63

63

10

0153 80

80

10

0153 96

100

10

0153 97

125

400

0102 63

Pack

Cat. Nos.

Miniature type 5 x 20

Type F (fast acting) fuse

Ceramic body

Conform to IEC 60127-2

For use with transformers (see p. 106),

Viking 3 terminals (see p. 132) etc.

Rating

Voltage ±

Breaking

(Amps)

(Volts)

capacity (Amps)

10

0102 02

0·2

10

0102 05

0·5

10

0102 06

0·63

10

0102 10

1

10

0102 12

1·25

10

0102 16

1·6

10

0102 20

2

250

1 500

10

0102 25

2·5

10

0102 30

3·15

10

0102 50

5

10

0102 63

6·3

10

0102 96(1)

10

250

500

(1) Overrating not described by standards
