ADA4432-1/ADA4433-1

Data Sheet

Rev. E | Page 12 of 25

ADA4433-1 TYPICAL PERFORMANCE CHARACTERISTICS

TA = 25°C, +VS = 3.3 V, V−IN = 0.5 V, RL = 150 Ω, unless otherwise specified.

Figure 25. Frequency Response at Various Output Amplitudes

Figure 26. Large Signal Frequency Response at Various Temperatures

Figure 27. 1 dB Flatness Response at Various Load Resistances

Figure 28. 1 dB Flatness Response at Various Output Amplitudes

Figure 29. 1 dB Flatness Response at Various Temperatures

Figure 30. Group Delay vs. Frequency

–66

–60

–54

–48

–42

–36

–30

–24

–18

–12

–6

0.1

100

FREQUENCY (MHz)

VOUT = 0.2V p-p

VOUT = 2.0V p-p

–66

–60

–54

–48

–42

–36

–30

–24

–18

–12

–6

0.1

100

FREQUENCY (MHz)

+125°C

+25°C

–40°C

VOUT = 2.0V p-p

3.0

3.5

4.0

4.5

5.0

5.5

6.0

6.5

7.0

0.1

FREQUENCY (MHz)

RLOAD = 75Ω

RLOAD = 150Ω

VOUT = 2.0V p-p

RLOAD = 100Ω

3.0

3.5

4.0

4.5

5.0

5.5

6.0

6.5

0.1

100

FREQUENCY (MHz)

VOUT = 0.2V p-p

VOUT = 2.0V p-p

3.0

3.5

4.0

4.5

5.0

5.5

6.0

6.5

0.1

100

FREQUENCY (MHz)

+125°C

+25°C

–40°C

VOUT = 2.0V p-p

100

0.1

100

FREQUENCY (MHz)
