12
Carlo Gavazzi Industri A/S
PD30CTDx10BPxxIO - IO-Link
PD30CTDx10BPxxIO ENG
28/04/2021
Power supply
ON
Target (Object)
Present
Break output
(N.C.)
ON
Tv
Make output
(N.O.)
ON
Tv
Response times
Operating frequency (f)
≤ 1000 Hz
Response times
≤ 500 µs
OFF-ON (t
ON)
≤ 500 µs
ON-OFF (t
OFF)
Indication
Green LED
Yellow LED
Power
Function
SIO and IO-Link mode
ON
ON
ON
ON (stable)* SSC1
ON
OFF
ON
OFF (stable)* SSC1
OFF
OFF
OFF
OFF (Not stable) SSC1
Flashing 1 Hz
(10% or 90% du-
tycycle )
-
ON
Connected via IO-Link
-
Flashing 10 Hz
50% dutycycle
ON
Output short-circuit
-
Flashing 0.5…20
Hz
50% dutycycle
ON
Timer triggered indication
SIO mode only
-
Flashing 1 HZ
ON 100 ms
OFF 900 ms
ON
External teach by wire.
Only for single point mode.
-
Flashing 1 HZ
ON 900 ms
OFF 100 ms
ON
Teach time window (3 - 6 sec).
-
Flashing 10 HZ
ON 50 ms
OFF 50 ms
Flashing for 2 sec
ON
Teach time out (12 sec).
-
Flashing 2 HZ
ON 250 ms
OFF 250 ms
Flashing for 2 sec
ON
Teach successful.
O-Link mode only
Flashing 1 HZ
ON 900 ms
OFF 100 ms
-
ON
Sensor is in IO-Link mode.
Flashing 2 Hz
50% dutycycle
ON
Find my sensor
*See operation diagram
