ILS Driver Part No.

Rating Watts

Current

LED Driver

Forward Voltage

OTi-DALI-10/220-240/700-NFC

10W

150-700mA

2.5-45V

OTi-DALI-50/220…240/1A4-LT2-FAN-

NFC

50W

600-1400mA

15-54V

OT-20/170-240/800-4DIMLT2-G2-CE

20W

200-1050mA

10-38V

Thermal Interface Material Options

ILS have produced a range of High-performance, cost effective Thermal Interface Materials to match perfectly their

standard products. Our product fills the air pockets between the two surfaces, forming a continuous layer to conduct

heat away from the LED to the Heatsink. ILS offer our TIM in three options – double sided adhesive, single sided

adhesive and non adhesive.

Product

Non Adhesive

Single Sided Adhesive

Double Sided Adhesive

1 PowerStar

ILA-TIM-STAR-0A

ILA-TIM-STAR-1A

ILA-TIM-STAR-2A

Assembly Information

z

The mounting of the OSLON® Square Uniform 1 PowerStar has to be on a metal Heatsink.

z

In order to optimise the thermal management, the metal surface needs to be clean (dirt and oil free) and planar for

the best contact with the LED module. A thermal grease or heat transfer material is highly recommended.
