ST10C167
38/65
XX - ELECTRICAL CHARACTERISTICS
XX.1 - Absolute maximum ratings
Note
Stresses above those listed under “Absolute Maximum Ratings” may cause permanent damage
to the device. This is a stress rating only and functional operation of the device at these or any
other conditions above those indicated in the operational sections of this specification is not
implied. Exposure to absolute maximum rating conditions for extended periods may affect device
reliability. During overload conditions (V
IN>VDD or VIN<VSS) the voltage on pins with respect to
ground (V
SS) must not exceed the values defined by the Absolute Maximum Ratings.
XX.2 - Parameter interpretation
The parameters listed in the following tables
represent the characteristics of the ST10C167
and its demands on the system. Where the
ST10C167 logic provides signals with their
respective timing characteristics, the symbol “CC”
for Controller Characteristics is included in the
“Symbol” column.
Where the external system must provide signals
with their respective timing characteristics to the
ST10C167,
the
symbol
“SR”
for
System
Requirement is included in the “Symbol” column.
Symbol
Parameter
Value
Unit
VSS
Voltage on VDD pins with respect to ground
-0.5, +6.5
V
VSS
Voltage on any pin with respect to ground
-0.3 to VDD +0.3
V
Input current on any pin during overload condition
-10, +10
mA
Absolute sum of all input currents during overload condition
|100|
mA
Ptot
Power Dissipation
1.5
W
Tamb
Ambient Temperature under bias
-40, +125
°C
Tstg
Storage Temperature
-65, +150
°C
